Application Scope:
Vacuum oil filling plant is mainly applied in filling oil under vacuum to amorphous alloys transformer, distribution transformer, oil-immersed instrument transformer and other electric insulation product (drying could be selected according to product characteristics).
Characteristics:
Technology advantages:
Since 1992 - KAIXUAN VACUUM has been committed to develop the process and configuration of vacuum oil treatment.
3D & modular design, assemble & test before shipment, easy operation and maintenance.
In 2014 - hosted and drawn up National Standard "Amorphous alloy core transformer vacuum filling plant" (JB/T 12010-2014), "High voltage mutual inductor vacuum drying & filling plant" (JB/T 12011-2014), "High voltage mutual inductor compositive vacuum filling plant" (JB/T 12012-2014) and issued by Ministry of Industry and Information Technology of China (MIIT).
Specifications For Reference
Dimension/mm | Ultimate vacuum | Leakage rate | Operating temp. | Temp. accuracy | Control mode |
Ф2400×4000 | ≤50Pa(unload) | ≤100Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
Ф2600×4000 | ≤50Pa(unload) | ≤100Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
Ф3000×4000 | ≤50Pa(unload) | ≤100Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
4000×2000×2000 | ≤50Pa(unload) | ≤100Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
4500×2000×2000 | ≤50Pa(unload) | ≤100Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
5000×2000×2000 | ≤50Pa(unload) | ≤100Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
6000×2000×2000 | ≤50Pa(unload) | ≤100Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
Successful Project Example(s):
ZHEJIANG DETONG, JIAXING AINENGDE, HONGGUANG ELECTRIC, HENAN LONGXIANG ELECTRIC, JIANGSU GUANGTE, HUNAN TIANWEI, FOSHAN HUIWANG, SENYUAN ELECTRIC HENAN, etc.
Successful Project Example(s):
JIANGSU GUANGTE ELECTRIC
