Application Scope:
LFH vacuum drying plant is mainly applied for drying (under vacuum state) all kinds of high voltage insulation products for transmission and distribution transformer industry, such as: transformer (10kV-220kV) etc.
Characteristics:
Technical advantages: We cooperated with Wilson and GE Turkey and developed this technology based on mass of process test and actual running. LFH vacuum drying has short drying time, less energy, and high drying efficiency etc. advantages.
Marketing advantages: Our LFH vacuum drying plants have been exported to the Australia, Turkey and other countries. Kaixuan is first company to develop successfully this LFH technology in China, has original and core technology advantages.
The equipment is used for drying oil immersed power transformer under vacuum .
Add hot air circulation function to better improve drying effect.
Simultaneously add vacuum filling function, vacuum drying and filling process can be realized in one equipment, reduce largely transformer manufacturing time, improve efficiency.
Main Specification as below:
Dimension/mm | Ultimate vacuum | Leakage rate | Operating temp. | Temp. accuracy | Control mode |
Ф1200×2400 | ≤50Pa(unload) | ≤500Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
4000×2000×2000 | ≤50Pa(unload) | ≤500Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
4000×2500×2500 | ≤50Pa(unload) | ≤500Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
5000×2500×3000 | ≤50Pa(unload) | ≤500Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
6000×2500×3000 | ≤10Pa(unload) | ≤500Pa.L/S | 115±5℃ | ±5℃ | Auto control by HMI |
Pls contact with us if needed.
